Name: 35m HDMI 2.1 8K HDBaseT Extender with IR/RS-232 Passthrough, Audio De-embed, and Bi-directional PoH
Brand: WYRESTORM
SKU: EX-35-8K
Availability: OutOfStock

35m HDMI 2.1 8K HDBaseT Extender with IR/RS-232 Passthrough, Audio De-embed, and Bi-directional PoH

$900.00

SKU: EX-35-8K

The EX-35-8K is a robust solution for extending high-bandwidth video and control signals for residential and corporate installations. It’s features include support for cutting-edge HDMI 2.1 resolutions, delivering 8K@30Hz (or 8K@60Hz 4:2:0) and 4K@120Hz (4:4:4) video up to 35m over a single Cat5e/6 cable, or up to 40m over Cat6a/7, ensuring future-proof performance with a 40Gbps data rate and HDCP 2.3 compliance. Installation is simplified through Bi-direction PoC (Power over Cable), requiring only one power adapter for the entire link, while integrated RS232 and Bi-direction IR Pass-through provide comprehensive control. Furthermore, the unit offers professional audio handling with a balanced de-embedded audio output on the Receiver (RX) for connecting to dedicated sound systems.

Out of stock

Technical Specification
Additional Features

Technical Specification

AUDIO & VIDEO

Input/Output Signal Type

HDMI 2.1, HDCP 2.3

Max Input/Output Resolutions

VESA:
5120×2160@60Hz
5120×1440@60Hz
2560×1440@60Hz
2048×1152@60Hz
1920×1200@60hz

HDTV:
7680 x 4320p@60Hz
4096 x 2160p@120Hz
3840 x 2160p@120Hz
1920 x 1080p@240Hz
1280x720p@120Hz

Note: 7680 x 4320P @48Hz/50Hz/60Hz supports only YCbCr 4:2:0.

Maximum Data Rate

HDMI: 40Gbps

Audio Formats

HDMI IN/OUT: Supports multichannel audio up to PCM 7.1, including PCM 2.0/5.1/7.1ch, Dolby Digital, Dolby Digital Plus, Dolby TrueHD, Dolby Atmos, DTS 5.1, DTS-HD Master Audio and DTS:X
AUDIO OUT: PCM 2.0ch

Transmission Distance

Cat5e/6
1080P@60Hz: 197ft/60m
4K@60Hz, 8K@60Hz 4:2:0: 115ft/35m

Cat6a/7
1080P@60Hz: 230ft/70m
4K@60Hz, 8K@60Hz 4:2:0: 131ft/40m

HDMI
4K@30Hz, 1080P@60Hz Input/Output: 33ft/10m
4K@60Hz Input: 33ft/10m
4K@60Hz Output: 16ft/5m
8K@60Hz 4:2:0, 4K@120Hz, 8K@30Hz Input/Output: 10ft/3m

POWER

Power Supply

DC 12V 2A

Power Consumption

11.4W (Pair, via PoC)

Additional Features

LONG-RANGE HDBT EXTENSION

Transmit crystal-clear video over a single Cat cable:

Up to 35m for 8K/4K video on Cat5e/6
Up to 40m for 8K/4K video on Cat6a/7

BI-DIRECTIONAL POH

Power is delivered over the HDBT cable, meaning you only need a single power supply (included) at either the Transmitter (TX) or Receiver (RX) unit, simplifying installation behind displays.

CONTROL EXTENSION

Seamlessly manage all connected devices with bi-directional IR Pass-through and RS232 Pass-through (up to 115200 bps), allowing central control systems to communicate with sources and displays at either end.
