1G SFP Multimode Transceiver
$58.00
SKU: SR-1G-MM-SFP
The SR-1G-MM-SFP is a hot-pluggable, small form-factor pluggable (SFP) optical transceiver designed for short-range data communication over multimode fiber. Operating at 850nm with VCSEL laser technology, it delivers up to 1.25Gbps transmission rates and supports link distances up to 550 meters. This module is ideal for Gigabit Ethernet, Fibre Channel, and other optical networking applications requiring high performance, low power consumption, and digital diagnostics.
Available on backorder
Technical Specifications
Form Factor. SFP (Hot-pluggable)
Data Rate 1.25 Gbps
Laser Wavelength. 850 nm
Connector LC duplex
Max Distance 550m (50/125 µm MMF) / 300m (62.5/125 µm)
Power Supply +3.3V
Power Consumption < 1W
Operating Temperature. 0°C to +70°C
Transmitter Output Power -9.5 to -3 dBm
Receiver Sensitivity. < -17 dBm
DDM / Diagnostics. Supported (Digital Optical Monitoring)
Compliance. IEEE 802.3z, MSA SFP, FDA, IEC60825-1
Applications 1G Ethernet, Fibre Channel, Switch Links
