4-Input 4K Presentation Switcher with USB C 60W PD and Matrix Outputs, USB 3.0, Multiview & Wireless Casting
$2,900.00
SKU: SW-640L-TX-W
The SW-640L-TX-W is an advanced wireless presentation and conferencing system, tailored to meet the dynamic requirements of modern meeting spaces and conference rooms. This upgraded model boasts significant enhancements. Key improvements include two USB-C inputs with 60W PD, now featuring Multi Stream Transport (MST) support to unlock advanced connectivity and multi-display workflows. The switcher also includes an upgraded USB 3.0 switcher, further enriched by the support for a wireless host through the APO-DG2/APO-DG2-PRO. This addition allows for more flexible and convenient connections.
AUDIO AND VIDEO
Inputs
2x HDMI In: 19-pin Type A
2x USB-C
Wireless Video from Airplay or Miracast Source
APO-DG2 casting dongle (sold seperatley)
Outputs
2x HDMI Out: 19-pin Type A
1x Analog Audio Out (5-pin Phoenix Male Connector)
Audio Formats
2ch PCM
Output Video Encoding
HDMI
Video Resolutions (Max)
HDMI Out 1 – 3840x2160p @60Hz 4:4:4
HDMI Out 2 – 3840x2160p @30Hz 4:4:4
Supported Standards
DCI | RGB
Maximum Pixel Clock
300MHz
COMMUNICATION AND CONTROL
HDMI
HDMI Out 1 – HDCP 2.2
HDMI In & HDMI Out 2 – HDCP 1.4
USB
3x USB 3.0 Type A device ports | 5v 1000mA per port
2x USB 3.0 Type B host ports (assignable)
RS-232
1x 4-pin Phoenix (API control) | Provides 12V Power
LAN
3x 8-pin RJ-45 Ethernet Ports
Wireless
4x Wi-Fi Antennas | IEEE 802.11 a/b/g/n/ac | Dual-band 2.4 & 5GHz | WEP, TKIP, AES, WPA, WPA2
POWER
Power Supply
20V 10A
Max Power Consumption
160W
Features
- Automatic or manual switching of 4 connected sources (2 HDMI & 2 USB-C) with assignable USB host connection
- 60W PD on the USB C Ports
- Supports input resolutions up to 4K30 4:4:4 via USB-C or HDMI
- Wireless screensharing via Apple Airplay or Miracast
- Dual output via HDMI
- Multiview processing up to 4 simultaneous sources
- Analog audio output allows extraction of Audio.
- Compatible with all major conference software including Zoom, Microsoft Teams, Cisco WebEx and more
- Built-in USB 3.0 hub for connection of peripheral devices such as speakerphones or cameras
- Fast Switching in both single view and Multiview modes
- USB-C input supports alt-mode for both A/V, Ethernet, and Data communication over a single cable
- API uses Telnet over TLS for secure and encrypted communication
- Integrated webserver for control and configuration via HTTPS
- Easily mountable under a table or desk with included mounting brackets
- Built-in wireless access point for secure and isolated communication to screensharing devices
- Wireless access point supports custom SSID, password and screensharing access PIN
- Integrated ‘Guide Screen’ used to provide end-users with simple instructions to get connected
- Custom ‘Guide Screen’ can be uploaded to include company information, logos, or specific connection information
- Relay and PA Sensor
